JBL

JBL APEX AMPLIFIER PA1502 750W 2 CHANNEL

In stock
Click & Collect - Ready within 2 business hours
Same-Day Dispatch – Express orders before 2pm
$299.90 AUD inc. GST
Product Add-ons
Marine Petrol Dry Snapback Hat
Marine Petrol Dry Snapback Hat
$29.95 AUD inc. GST
Product details
  • Vendor JBL
  • SKU 117398
Description Shipping information

The JBL Apex PA1502 is the specialist of the Apex family. While other models focus on powering multiple speakers, this 2-channel powerhouse is designed for high-output stereo pairs or driving a dedicated subwoofer in a "micro" footprint.

High-Efficiency 2-Channel Power

Despite its tiny frame—smaller than a standard brick—the PA1502 delivers serious wattage thanks to its high-efficiency Class D design:

  • Strong Stereo Output: Delivers 100W RMS x 2 at 4 ohms, or 150W RMS x 2 at 2 ohms. This makes it perfect for driving high-performance tower speakers or high-end marine components.

  • Subwoofer Ready (Bridged): Bridge the amp to mono mode to deliver a massive 300W RMS into a single 4-ohm load—plenty of power for a 10-inch or 12-inch marine subwoofer.

  • Selectable Bass Boost: Dial in the punch with a 3-position bass boost (0, 6, or 12dB at 45Hz). This feature is specifically designed to add depth when the amp is in Low-Pass mode for subwoofers.

Built for Harsh Environments

Engineered for boats, ATVs, and motorcycles, the PA1502 is built to endure:

  • Conformal-Coated PCB: The internal electronics are fully "marinized" to resist corrosion from humidity, salt air, and spray.

  • Ultra-Compact Aluminum Chassis: Acts as a massive heat sink to keep the Class D circuitry cool while fitting into the tightest installation spots.

  • Standard-Setting Durability: Like its siblings, it has survived "torture tests," including extreme temperature cycling and prolonged UV exposure.

Technical Specifications

Feature Specification
Peak Power 750W
RMS Power (4Ω) $100\text{W} \times 2$
RMS Power (2Ω) $150\text{W} \times 2$
RMS Bridged (4Ω) $300\text{W} \times 1$
Crossover All/High/Low-Pass (@ 60/80/120Hz)
Bass Boost 0, 6, 12dB @ 45Hz
Frequency Response 20Hz – 20kHz
Dimensions 170mm x 85mm x 45mm

Why Choose the PA1502?

The PA1502 is the best choice if you already have a 4-channel amp for your cabin speakers and simply need a dedicated, weather-resistant amp for a subwoofer. It’s also the go-to for motorcycle fairings where you only have two speakers but want them to be as loud and clear as possible.

PA1502
